Print Head / Ink

Type

Permanent (Replaceable)

Number of Nozzles

Total 1,792 nozzles

Ink Cartridges

GI-70 (Pigment Black / Cyan / Magenta / Yellow)

Maximum Printing Resolution

4800 (horizontal)*1 x 1200 (vertical) dpi

Print Speed*2

Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions

Document (ESAT/Simplex)

Approx. 13.0 ipm (black) / 6.8 ipm (colour)

Document (FPOT Ready / Simplex)

Approx. 9 sec (black) / 14 sec (colour)

Photo (4 x 6") (PP-201/Borderless)

Approx. 45 sec

Printable Width

Up to 203.2 mm (8"), Borderless: Up to 216 mm (8.5")

Printable Area

Borderless Printing*3

Top/Bottom/Right/Left margin: Each 0 mm

Bordered Printing

#10 Envelope/DL Envelope:
Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mm

127 x 127 mm:
Top 6 mm / Bottom 6 mm / Right 6 mm / Left 6 mm

89 x 89mm / 4 x 4":
Top 5 mm / Bottom 5 mm / Right 5 mm / Left 5 mm

LTR / LGL:
Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mm

Other:
Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm

Bordered Auto 2-Sided Printing

Top / Bottom margin: 5 mm
Left / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm)

Support Media

Rear Tray

Plain Paper (64 - 105 g/m²)
Photo Paper Pro Platinum (PT-101)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Glossy II (PP-201/PP-208)
Matte Photo Paper (MP-101)
Glossy Photo Paper "Everyday Use" (GP-508)
High Resolution Paper (HR-101N)
Photo Paper Plus Semi-Gloss (SG-201)
Photo Stickers (PS-108/PS-208/PS-808)
Removable Photo Stickers (PS-308R)
Magnetic Photo Paper (PS-508)
Envelope

Cassette

Plain Paper (64 - 105 g/m²)

Paper Size

Rear Tray

A4, A5, B5, LTR, LGL, 4 x 6", 5 x 7", 7 x 10", 8 x 10"
Envelopes (DL, COM10), Square (5 x 5", 4 x 4", 89 x 89 mm), Card Size (91 x 55 mm)

[Custom size]
width 55 - 215.9 mm, length 89 - 676 mm

Cassette

A4, A5, B5, LTR

[Custom size]
width 148.0 - 215.9 mm, length 210 - 297 mm

Paper Size (Borderless)*4

A4, LTR, 4 x 6", 5 x 7", 7 x 10", 8 x 10"
Square (5 x 5",4 x 4",89 x 89 mm), Card Size (91 x 55 mm)

Paper Handling (Maximum Number)

Rear Tray

Plain Paper (A4, 64 g/m²) = 100
High Resolution Paper (HR-101N) = 80
Photo Paper: 4 x 6" = 20, 5 x 7" = 10

Cassette

Plain Paper (A4, 64 g/m²) = 250

Support Media for Auto 2-sided printing

Type

Plain Paper

Size

A4, A5, B5, LTR

Paper Weight

Rear Tray

Plain Paper: 64 - 105 g/m²
Canon paper: Max paper weight: Approx. 300 g/m²
(Photo Paper Pro Platinum PT-101)

Cassette

Plain Paper: 64 - 105 g/m²

Ink End Sensor

Electrode type and dot count type combined

Print Head Alignment

Auto/Manual

Scanner Type

Flatbed

Scanner Method

Optical Resolution*6

Optical resolution scan is available, only when you use TWAIN Driver.

1200 x 2400 dpi

Scanning Bit Depth (Input/Output)

Grayscale

16 bit/8 bit

Colour

RGB each 16 bit/8 bit

Line Scanning Speed*7

Grayscale

1.5 ms/line (300 dpi)

Colour

3.5 ms/line (300 dpi)

Maximum Document Size

Flatbed

A4/LTR (216 x 297 mm)

ADF

A4/LTR/LGL

Maximum Document Size

Flatbed

A4/LTR (216 x 297mm)

Compatible Media

Size

A4/A5/B5/LTR/LGL/4 x 6"/5 x 7"/
Square (5 x 5")/Card Size (91 x 55 mm)

Type

Plain Paper
Photo Paper Pro Platinum (PT-101)
Photo Paper Pro Luster (LU-101)
Photo Paper Plus Semi-Gloss (SG-201)
Glossy Photo Paper "Everyday Use" (GP-508)
Matte Photo Paper (MP-101)
Photo Paper Plus Glossy II (PP-201)
Photo Paper Plus Glossy II (PP-208)

Image Quality

3 positions (Economy, Standard, High)

Density Adjustment

9 positions, Auto intensity (AE copy)

Copy Speed*8

Based on ISO/IEC 24734
Click here for summary report
Click here for Document Print and Copy Speed
Measurement Conditions

Document (Colour) (sFCOT/Simplex) / (sESAT/Simplex)

Approx. 22 sec / approx. 3.9 ipm

Multiple Copy

Black/Colour:

Max. 99 pages

Type

Desktop Transceiver (Super G3 / Colour Communication)

Applicable Line

PSTN

Transmission Speed*9

Approx. 3 sec (black) / approx. 1 min (colour)

Fax Resolution

Black

8 pels/mm x 3.85 lines/mm (Standard)
8 pels/mm x 7.7 lines/mm (Fine)
300 dpi x 300 dpi (Extra Fine)

Colour

200 × 200 dpi

Print Size

A4, LTR, LGL

Scanning Width

208 mm (A4), 214 mm (LTR)

Modem Speed

Maximum 33.6 kbps (Automatic fall back)

Compression

Black

MH, MR, MMR

Colour

JPEG

Gradation

Black

256 levels

Colour

24 bit Full colour (RGB each 8 bit)

ECM (Error Correction Mode)

ITU-T T.30 compatible

Automatic Dialling

Group Dialling

Max. 19 locations

Transmission/Reception Memory*10

Approx. 50 pages

Type

Windows / Mac

Destination Number

1 location

Black/Colour

B/W transmission only

Protocol

SNMP, HTTP, TCP/IP (IPv4/IPv6)

Wired LAN

Network Type

IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T)

Data Rate

10M/100Mbps (auto switchable)

Wireless LAN

Network Type

IEEE802.11n/g/b

Frequency Band

2.4 GHz

Channel*11

1 - 13

Range

Indoor 50 m (depends on the transmission speed and conditions)

Security

WEP64/128 bit
WPA-PSK (TKIP/AES)
WPA2-PSK (TKIP/AES)

Direct Connection (Wireless LAN)

Available

AirPrint

Available

Windows 10 Mobile

Available

Mopria

Available

Google Cloud Print

Available

Canon Print Service
(for Android)

Available

PIXMA Cloud Link
(from smartphone/tablet)

Available

Easy Photo-Print Editor
(for iOS/for Android)

Available

Canon PRINT Inkjet/SELPHY
(for iOS/for Android)

Available

Windows 10 / 8.1 / 7 SP1
(operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)

OS X 10.11.6
macOS 10.12～ macOS 10.14

Operation Panel

Display

2-Line LCD

Language

32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese

Interface

Hi-Speed USB 2.0

PictBridge (Wireless LAN / LAN)

Available

Operating Environment*13

Temperature

5 - 35°C

Humidity

10 - 90% RH (no dew condensation)

Recommended Environment*14

Temperature

15 - 30°C

Humidity

10 - 80% RH (no dew condensation)

Storage Environment

Temperature

0 - 40°C

Humidity

5 - 95% RH (no dew condensation)

Quiet Mode

Available

Acoustic Noise (PC Print)

Plain Paper (A4, B/W)*15

Approx. 47.0 dB(A)

Power

AC 100-240 V, 50/60 Hz

Power Consumption

OFF

Approx. 0.3 W

Standby (scanning lamp is off)
USB connection to PC

Approx. 1.0 W

Standby (all ports connected, scanning lamp is off)
[EU only - for ErP Lot 26 regulation]

Approx. 1.8 W

Time to enter Standby mode [EU only - for ErP Lot 26 regulation]

Approx. 11 min 10 sec.

Copy*16
USB connection to PC

Approx. 15 W

Environment

Regulation

RoHS (EU, China), WEEE (EU)

Duty Cycle

Up to 5,000 pages/month

Dimension (WxDxH)

Factory Configuration

Approx. 403 x 369 x 234 mm

Output/ADF trays extended

Approx. 403 x 701 x 305 mm

Weight

Approx. 9.6 kg

Plain Paper (A4 pages)
(ISO/IEC 24712 test file)*17

Standard:
GI-70 PGBK: 6,000
GI-70 C/M/Y: 7,700

Economy:
GI-70 PGBK: 8,300
GI-70 C/M/Y: 7,700

Photo Paper PP-201, 4 x 6"
(ISO/IEC 29103 test file)*17

Standard:
GI-70 PGBK: NA
GI-70 C/M/Y: 2,200
